Токарный станок по металлу Index G200 C

This 5-axis Index G200 C turn-mill centre was manufactured in 2000. Consider the opportunity to buy this Index G200 C turn-mill centre. Contact us for more information.
Additional equipment
Synchronous device for counter spindle machining
Tool carrier 3 for synchronous spindle (rear end machining)
Additional milling spindle
Thread milling and polygon turning device
Gripperless tool changer (6 tools, HKS-50 B, KM40)
Workpiece handling WHU100
Machine Benefits
Technical Machine Benefits
Space requirement (without material guide): 3580 x 3108 mm
Control unit: resolution: 0. 001 mm (input/output/correction)
Comprehensive movement range with multiple axes configuration
High precision with 0. 001 mm resolution in numerical control
Versatile expansion stages and additional equipment for enhanced functionality
Extra Information
Movement
Cross slide 1 (top) - XYZB axes:
X-axis: Slide path 155 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm
Y-axis: Slide travel 120 mm, feed force 10000 N, rapid traverse 7.5 m/min, resolution 0.0005 mm
Z-axis: Slide path 590 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm
B-axis (rotating): 360° swivel range, angular steps 5° (with locking), resolution 0.001° (with clamping), switching time for 180°: 1 s
Cross slide 2 (bottom) - XZ axes:
X-axis: Slide travel 105 mm, feed force 5000 N, rapid traverse 20 m/min, resolution 0.0005 mm
Z-axis: Slide path 307 mm, feed force 5000 N, rapid traverse 30 m/min, resolution 0.001 mm

Turret
Turret right:
X-axis: Slide path 120 mm
Z-axis: Slide travel 400 mm

Tail Stock
Center distance: 400 mm
Pressure force (max): 5500 N
Drive: Hydraulic or electric

Media
Power supply:
400 V, 50/60 Hz
Connected load: 20-45 kVA
Current consumption: 35-80 A

Hydraulic system:
Delivery rate: 18 l/min
System pressure: 90 bar
Filling capacity: 70 liters

Cooling lubricant system:
Pump capacity (switchable): 20 l/min at 18 bar / 50 l/min at 3 bar / 60 l/min at 5-7 bar
Filling quantity: Approx. 230 liters

Chip conveyor: Hinged belt or scraper
Workpiece holder: Main spindle: DB5 internal mount / D140 external mount, optional short taper
Counter spindle: D140 external mount (only tensile clamping permitted for collet and chuck clamping)

1st spindle data (main/counter spindle):
Spindle clearance (collet clamping): Variants: 30 mm / 42 mm / 60 mm / 65 mm
Spindle Ø in front bearing: 75 mm (with 30 mm clearance) / 85 mm (42 mm) / 100 mm (60+65 mm)
Speed (max): 7500 rpm (30 mm) / 6300 rpm (42 mm) / 5000 rpm (60 mm)
Spindle nose: ISO 702/1 (size 4 or 5)
Chip diameter (workpiece Ø): 110-130 mm (30 mm) / 140-160 mm (42 mm) / 165 mm (60 mm)
Torque (Md max 100%): 33-62 Nm (30 mm) / 35-95 Nm (42 mm)
Power (P max 100%): 7-13 kW (30 mm) / 7.5-20 kW (42 mm)
application type: Turning
Location: Germany
machine type: Turn-Mill Centre
control unit brand: INDEX
Control Brand: INDEX
Control Model: C200-4 / C200-8
Machine Depth: 3580 mm
